Light drainage pump type ABS Robusta for pumping water and wastewater in domestic and commercial areas
Light drainage pump type ABS Robusta for pumping water and wastewater in domestic and commercial areas

Light drainage pump type ABS Robusta

For the smaller pumping challenges

The Robusta 200 and 300 models are plug-in, submersible pumps designed to remove wastewater containing solids up to 10 mm. The pump and motor form a pressure-tight encapsulated fully flood-proof unit .
Main benefits
  • Pumps down to 3 mm when the detachable suction ring is fitted into the screen
  • Easy installation with Schuko plug and 10 m cable
  • Automatic operation with built-in float switch for reliable operation
  • Backflow is prevented with built-in check valve
  • Fits in small sumps from 300 x 300 mm
  • Suitable for both manual and automatic operation with the unique hand/auto switch
Main applications
  • Domestic and commercial wastewater without toilet waste
  • Drainage of pits and flooded cellars
  • Thermal sensors
  • Three lip seals lubricated by a grease chamber
  • Protection type IP 68
  • Stainless steel rotor shaft supported in lubricated-for-life ball bearings
  • Motor housing made of corrosion-resistant material, and the outer jacket and impeller of durable plastics
  • 60 Hz version available with approval (UL, CSA)
Key characteristics
Capacities Up to 12 m3/h / 52 US gpm
Heads 8.5 m / 28 ft
Temperatures 40°C up to 60°C / 104°f up to 140°F
Discharge sizes G 1¼”
Maximum speed of rotation 2,900 rpm
